Agilent E1458A High-Frequency Oscilloscope, 200 MHz Bandwidth, 2 Channels

Frequency Range:10 Hz to 3 GHz

Output Power:-20 dBm to +13 dBm

Phase Noise:< -100 dBc/Hz at 10 kHz offset

Harmonic Distortion:-70 dBc

Non-Harmonic Distortion:-55 dBc

Spurious Response:-70 dBc

Modulation Types:AM, FM, PM, PWM, PULSE, FSK, PSK, ASK

Interface:RS-232, GPIB

Power Supply:100 to 240 VAC, 50/60 Hz

    The Agilent E1458A modular signal analyzer offers a versatile platform for advanced signal analysis. With its wide frequency range from 2 Hz to 26.5 GHz, it supports both wideband and narrowband signal analysis, making it an ideal choice for testing modern wireless communications and radar systems. Its exceptional dynamic range of 150 dB @ 1 GHz ensures precise measurements even under challenging conditions. The phase noise performance of -110 dBc/Hz @ 10 kHz offset guarantees accurate phase stability, critical for applications like electronic warfare. Equipped with a user-friendly 5.7-inch color TFT display and multiple interface options including GPIB, USB, and LAN, this signal analyzer facilitates seamless integration into existing test environments. Weighing just 12 lbs, the compact design at 17.2 x 12.8 x 7.2 inches (HxWxD) makes it highly portable and easy to install in a variety of setups. Experience unmatched precision and reliability with the Agilent E1458A modular signal analyzer.
