CKD LYX-0507 Electric Actuator for Industrial Automation Applications

Brand:CKD

Model:LYX-0507

Module Category:Modular Control Unit

Input Voltage Range:100-240V AC

Output Voltage Range:24V DC

Operating Temperature:-20°C to +70°C

Protection Rating:IP65

Communication Interfaces:RS485, Ethernet

Control Outputs:4x Relay Outputs, 2x Analog Outputs

Monitoring Inputs:8x Digital Inputs, 4x Analog Inputs

Weight:2.5kg

Dimensions:150mm x 100mm x 70mm (L x W x H)

    The CKD LYX-0507 linear actuator is built for demanding industrial environments where precision and reliability are paramount. Designed with robust materials, it ensures long-lasting performance even under harsh conditions.

    Equipped with a linear motion mechanism, this actuator offers smooth and accurate movements, making it suitable for various automation tasks such as pick-and-place operations, assembly lines, and robotic systems.

    The actuator features a compact design, allowing for easy integration into existing machinery without compromising on space. Its IP65 protection rating makes it resistant to dust and water ingress, enhancing its versatility and durability.

    With a stroke length of 50 mm and a force output of 70 N, the CKD LYX-0507 is capable of handling a wide range of applications. Its repeatability of ±0.01 mm ensures consistent performance, meeting the stringent requirements of modern manufacturing processes.

    This actuator operates at a voltage of 24 V DC and has a speed of 50 mm/s, providing efficient and reliable operation. It is compatible with a variety of control systems, making it a versatile solution for industrial automation.
