Pacific Scientific H32NCHA-LNN-NS-00 – High Precision Linear Actuator Module

Manufacturer:Pacific Scientific

Model:H32NCHA-LNN-NS-00

Module Type:High-Performance Control Module

Voltage Rating:24 VDC

Current Rating:1 A

Operating Temperature Range:-40°C to +85°C

Humidity Range:0% to 95%, non-condensing

Communication Protocol:Modbus RTU

Number of Channels:32 Digital Inputs, 8 Analog Outputs

Response Time:1 ms

Weight:0.5 kg

Dimensions:160 mm x 100 mm x 70 mm

    The Pacific Scientific H32NCHA-LNN-NS-00 is an advanced linear actuator module that combines precision engineering with robust design. Designed for industrial environments, this module ensures smooth and accurate movement, making it suitable for a wide range of applications including packaging, material handling, and assembly lines.

    This actuator module is built to withstand harsh conditions with an IP65 environmental rating, ensuring longevity and reliability even in dusty or wet environments. The module features a powerful motor capable of generating up to 2000N of force, enabling it to handle demanding tasks.

    One of the key features of the H32NCHA-LNN-NS-00 is its precision. With an accuracy of ±0.01mm, it can perform fine adjustments and movements with exceptional accuracy, which is crucial for high-tolerance manufacturing processes. The stroke length of 100mm provides ample range for various applications.

    The module is compatible with a 24V DC operating voltage, making it easy to integrate into existing systems. Its speed range of 0-100mm/s allows for flexible control over the actuator’s movement, catering to different operational needs. Additionally, the compact dimensions of 200mm x 80mm x 70mm make it ideal for space-constrained environments.

    Installation and maintenance are straightforward thanks to the intuitive design of the H32NCHA-LNN-NS-00. The lightweight design (3.5kg) ensures ease of handling during installation, and the durable construction minimizes downtime due to wear and tear.
