Beckhoff EL4112 – Dual-Channel Analog Output Terminal, Designed for Industrial Control Applications

Number of Channels:2

Analog Output Type:Voltage or Current

Supply Voltage:12…48V DC

Output Current:0…20mA

Signal Processing:Single-ended or differential

Resolution:12-bit

Operating Temperature:-25°C…+70°C

Enclosure Protection:IP20

Dimensions:98x58x36mm

Weight:Approx. 70g

Communication Interface:K-Bus

    The Beckhoff EL4112 is a state-of-the-art dual-channel analog output terminal, specifically engineered for seamless integration into complex industrial automation systems. Its robust design ensures high reliability and accuracy in controlling various actuators, motors, and other equipment requiring precise voltage or current outputs.

    Each channel is equipped to handle a wide range of signal types, from 0 to 10VDC and 4 to 20mA, providing flexibility for diverse control applications. The terminal supports a maximum load resistance of up to 1 kilohm, making it suitable for a broad spectrum of load requirements.

    Built-in EtherCAT communication interface facilitates fast and efficient data exchange within the network, ensuring smooth operation and improved system responsiveness. The terminal’s low current consumption of typically 10mA helps in managing energy usage effectively without compromising on performance.

    Operating within an extended temperature range of -25°C to +60°C, the EL4112 is designed to withstand harsh industrial environments. It complies with IP20 enclosure rating, ensuring protection against dust but not against water ingress, suitable for indoor applications.

    With its terminal block connection type, the EL4112 offers easy installation and maintenance. The modular design allows for quick replacement and upgrades, enhancing the system’s flexibility and longevity. This terminal is an indispensable component for achieving precise control in today’s advanced manufacturing and automation sectors.
