GE SR745-W3-P5-G5-HI - Transformer Management Relay with Advanced Features

GE SR745-W3-P5-G5-HI – Transformer Management Relay with Advanced Features

In stock

The GE Multilin 745-W3-P5-G5-HI Transformer Management Relay is designed to protect and manage transformers of varying sizes, providing advanced monitoring and control capabilities. It supports high input voltages and is ideal for industrial applications requiring robust protection and efficient management.

Weight:4.8kg

Voltage Input Burden:Less than 0.025 VA at 120 V

Source VT:2 to 600 kV / 60 to 120 V

Number of Logic Inputs:16

Manufacturer:General Electric

Fuse Current Rating:3.15 A

Features:[“Enhanced Display”,”High Control Power”]

Software Version:EnerVista 745 Setup

Operating Temperature:-40°C to +60°C

Chassis:745 SR Series

Manual:745 Instruction Manual 1601-0161-A7

Input Voltage:60 to 120V

Display Resolution:40 Character LCD

The GE SR745-W3-P5-G5-HI Transformer Management Relay is meticulously engineered to provide unparalleled protection and management for power transformers, ranging from small to large scales. Its advanced features include an enhanced 40-character display and an expanded keypad, which facilitate easier manual entry of setpoints and real-time status alerts via multiple LEDs.

Built with robust engineering standards, this relay can be easily mounted on a standard 19” panel and is designed for efficient operation in diverse environmental conditions, including temperatures ranging from -40°C to +60°C. The high-quality materials and precise construction ensure long-lasting performance under demanding industrial settings.

With its user-friendly interface and comprehensive passcode security, the GE SR745-W3-P5-G5-HI ensures secure access and reliable operation. The 40-character LCD display provides clear visual feedback, enhancing operational efficiency and reducing the likelihood of errors.

The integrated IRIG-B input impedance feature allows for seamless synchronization and data exchange with other systems, making it an indispensable component in modern power distribution networks. Its modular design supports easy maintenance and upgrades, ensuring continuous optimal performance.

Designed with adaptability in mind, the GE SR745-W3-P5-G5-HI can be deployed as a standalone unit or integrated into existing relay systems within the GE Multilin 745 series. This flexibility makes it an ideal solution for various industrial applications, including renewable energy, manufacturing plants, and utility companies.
