Tektronix 5A18N Signal Generator, High Precision Waveform Generation Module

Output Channels:2

Waveforms:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary

Frequency Range:0.1 µHz to 20 MHz

Amplitude Range:20 mVpp to 10 Vpp

Resolution:1 µHz / 1 µV

Accuracy:±0.1% of Setting ±1 Least Significant Digit

Output Impedance:50 Ω

Harmonics:Up to 5th Harmonic

Modulation Types:AM, FM, PM, FSK, PWM

Memory Depth:Up to 16k Points

Interface:USB, LAN, GPIB, RS-232

    The Tektronix 5A18N Signal Generator offers unparalleled precision and reliability, making it an essential tool for engineers and technicians in the field of industrial control systems. Its advanced signal generation capabilities enable users to test and measure a variety of electronic devices and systems.

    Equipped with a user-friendly interface and comprehensive connectivity options including USB, LAN, and GPIB, the Tektronix 5A18N facilitates seamless integration into existing laboratory and production environments. The device supports multiple waveform types, including sine, square, triangle, pulse, and arbitrary waveforms, catering to diverse application needs.

    With a frequency range from 1 MHz to 1 GHz and an output power up to 20 dBm, this signal generator ensures high-performance testing and calibration across a broad spectrum of frequencies. The phase noise of -120 dBc/Hz at 10 kHz offset guarantees minimal signal degradation, ensuring accurate and reliable measurements.

    Designed with durability and ease of use in mind, the Tektronix 5A18N features a robust build quality and intuitive controls. Its compact dimensions (432 mm x 92 mm x 461 mm) and manageable weight (18 kg) make it easy to integrate into any workspace.

    Whether you’re conducting rigorous research, developing new products, or maintaining existing systems, the Tektronix 5A18N Signal Generator delivers the precision and versatility needed to meet your most demanding requirements.
